Monitor MI-5000B Audiometer

Cost-effective microprocessor audiometer by Monitor Instruments that can be used alone or with computer testing software, such as CAT Audiometric Software.

Features simple operation, a large display that shows all thresholds, and both automatic and manual testing modes.

Calibration needed? We do that too!

Learn More


  • Simple-to-use
  • Rugged
  • LCD display shows all thresholds
  • Compatible with CAT software
  • Automatic and manual testing modes
  • Configurable starting ear
  • 8K optional
  • Talkover
  • Audible alerts for end of test and error conditions
  • Error messages displayed on screen
  • Pause and resume buttons


  • Frequencies: 500, 1K, 2K, 3K, 4K, 6K, 8K
  • Intensity range: 0 - 90 dB
  • Response window: 1.8 seconds
  • Calibration: Meets ANSI S3.6 1996, OSHA 1910.95
  • Dimensions: 2.75" x 7.50" x 9.00"
  • Power: 120 VAC, 60 Hz, 32 VA
  • Weight: 2.6 lbs.
  • Computer port: 9-pin RS-232


  • Audiometer
  • Ear phones
  • Response switch
  • Power supply
  • Patch cords
  • Operator manual
